Does this digital scope have a spectrum analyser function? Once the signal is digitised, it's 'only' a software function. You could look at the value of the second, third etc harmonics (100Hz, 150Hz etc) and compare it to the mains waveform.

sadly, no.



[DBK]

Why not do a comparison check against the 'mains' 230v?

I did that yesterday, the waveform looked identical.



[Gromett]

Went to look at the inverter but neither of your links to it works anymore

^{_{Subscribers  do not see these advertisements}}



[kevenh]

Went to look at the inverter but neither of your links to it works anymore

Could be the invertor here.
Just a search by the key words though



[DBK]

Went to look at the inverter but neither of your links to it works anymore

The links are out of date now but this one looks like it - although the price has gone up a bit - I only paid about £150 from memory. I didn't fit the remote control as I just turn it on and off with the isolating switch. But I think you do take a chance with these cheaper inverters. The reviews are mixed and I guess I've just been lucky.

If I ever have to remove it I'll have a look inside and see if there are any obvious filters for smoothing the supply.

Amazon product ASIN B07W4J13J5
www.amazon.co.uk/EDECOA-Power-Inverter-Remote-Controller/dp/B07W4J13J5/


But on the up side I've discovered the 'scope is working at RF frequencies - it was operator error by me - specifically trying to measure at the wrong point in the radio.



[kevenh]

The links are out of date now but this one looks like it - although the price has gone up a bit - I only paid about £150 from memory.

Amazon product ASIN B07W4J13J5
www.amazon.co.uk/EDECOA-Power-Inverter-Remote-Controller/dp/B07W4J13J5/

pfft! The invertor in my link has a display & is only £185.00 - but I've never owned an invertor or did any other comparisons between the two EDECOA's
